CONNECTOR INFORMATION

  • Gas tight interface joint
  • No solder required
  • Contacts are replaceable
  • Between-contact keying
  • Closed card entry
  • Reduced total backplane COST
  • Removable connector housing
  • Increased system reliability
  • Improves operating characteristics
  • Insulator automatically preloads
  • Contact at top

1 Closed-Entry Card Slot
2 Polarization Key
3 Insulator
4 Preload Barrier
5 Cantilever Contact
6 Insertion Shoulder
